1998-2000 GM Pick-up/Tahoe/Suburban/Yukon/Escalade: 5.0L/5.7L, Tube Size 1.5" O.D., w/A.I.R, 50-State Legal header CARB EO #D-115-16.
FLOWTECH's emissions-friendly headers are just the ticket for those who want the best of both worlds - top performance and a clean machine. All Shorty Smog Headers bolt on quickly and easily to the factory exhaust system, retaining all stock emissions equipment, and offering maximum horsepower gains plus increased efficiency! This is a 50-State Legal header C.A.R.B. EO #D-115-16.
- This is a 50-State Legal header C.A.R.B. EO #D-115-16.
- Sturdy 16 gauge tubing
- Extra thick 3/8” flanges for a leak-free seal
- Designed as a direct fit replacement for factory exhaust manifolds
- Will accommodate all emission control devices
- Bolts directly to factory head pipe
- Complete with premium gaskets and hardware
Information:
Breaking in an engine with ceramic coated headers WILL result in damage to the coating and will VOID all warranties. Ceramic coated headers require several heat cycles to fully cure before they will withstand extreme heat. Flowtech recommends using cast iron exhaust manifolds or old headers to break in new engines to avoid coating damage. Please call Flowtech tech service at 270-781-9741 for additional information regarding ceramic coated exhaust products. The use of header wraps can cause the header tubes to crack or rust due to excessive heat and moisture build-up. Flowtech does not recommend the use of header wraps as this will void the warranty.
Application Summary:
| Year |
Make/Model |
| 1999-2000 |
Cadillac Escalade |
| 1998-1999 |
Chevrolet C1500 |
| 1998-1999 |
Chevrolet C1500 Suburban |
| 1998-2000 |
Chevrolet C2500 |
| 1998-1999 |
Chevrolet C2500 Suburban |
| 1998-2000 |
Chevrolet C3500 |
| 1998-1999 |
Chevrolet K1500 |
| 1998-1999 |
Chevrolet K1500 Suburban |
| 1998-2000 |
Chevrolet K2500 |
| 1998-1999 |
Chevrolet K2500 Suburban |
| 1998-2000 |
Chevrolet K3500 |
| 1998-2000 |
Chevrolet Tahoe |
| 1998-1999 |
GMC C1500 |
| 1998-1999 |
GMC C1500 Suburban |
| 1998-2000 |
GMC C2500 |
| 1998-1999 |
GMC C2500 Suburban |
| 1998-2000 |
GMC C3500 |
| 1998-1999 |
GMC K1500 |
| 1998-1999 |
GMC K1500 Suburban |
| 1998-2000 |
GMC K2500 |
| 1998-1999 |
GMC K2500 Suburban |
| 1998-2000 |
GMC K3500 |
| 1998-2000 |
GMC Yukon |
| Attributes |
| Air Injection Tubes |
Yes |
| Application |
Automotive |
| ASIN |
B000LT1YNM |
| Bolt size |
3/8-16 x 3/4, 3/8-16 x 3/4 |
| Bolts Included |
Yes |
| Brand |
Flowtech Exhaust, Flowtech Exhaust |
| C.A.R.B EO # |
D-115-16 |
| C.A.R.B. EO # |
D-115-16, D-115-16 |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| CARB (California) Compliant |
Yes, Yes |
| CARB EO# |
D-115-16 |
| Category |
Exhaust, Exhaust |
| Coated Finish |
Painted |
| Coating/Finish |
Painted |
| Collector Attachment |
3-Bolt Flange |
| Collector Diameter |
2.500 in., 2.50 inch |
| Collector Diameter (in.) |
2.50, 3.50 |
| Collector Reducer Included |
No |
| Collector Reducer Outlet Diameter |
N/A |
| Collector Tube Size |
OEM |
| Collector Tube Size (in.) |
OEM |
| Color |
Black, Black |
| Country of Origin (Primary) |
CN |
| Cylinder Head Flange Thickness |
5/16" |
| Design |
Shorty, Shorty |
| Drive |
2WD/4WD |
| EGT (Exhaust Gas Temperature) Port |
No |
| Emission Code |
1, 1, Legal US |
| Engine |
Chevrolet Small Block Gen I, Chevrolet Small Block Gen I |
| Engine Make/Size |
Chevy 5.7L (Vortec) |
| Finish |
Black Paint, Painted |
| Flange Thickness |
3/8", 0.3750 |
| Gasket Or Seal Included |
Yes |
| Grade Type |
Performance, Performance |
| Harmonized Tariff Code (Schedule B) |
8708925000 |
| Hazardous Material Code |
N |
| Head Style |
Shorty |
| Header Finish |
Black Paint, Black Paint |
| Header Series |
Shorty Smog |
| Header Style |
Shorty, Shorty |
| Life Cycle Status Code |
Available to Order |
| Main Piping Diameter |
1-5/8, 1.50 |
| Material |
Steel, Mild Steel |
| Mounting Hardware Included |
Yes, Yes |
| NAFTA Preference Criterion Code |
B |
| Oxygen Sensor Port |
No, No |
| part type |
Exhaust Header, Exhaust Header |
| Pipe Wall Gauge |
16 |
| Port Shape |
Round, Oval |
| Primary Tube Dia. |
1-5/8 inch, 1-5/8 inch |
| Primary Tube Diameter |
1.625 in., 1.875 in. |
| Primary Tubing Diameter |
1-5/8, 1-1/2 |
| Product Type |
Headers, Headers |
| Quantity |
Sold as a pair, Sold as a pair |
| Sale Category |
Exhaust |
| SDR Required Flag |
N |
| Sheen Level |
Satin, Satin |
| Sub Category |
Exhaust Manifolds, Exhaust Manifolds |
| Tube Diameter |
1.500 in. |
| Tube Direction |
Down Swept |
| Tube Material |
Mild Steel, Mild Steel |
| Tube Size |
1.5 |
| Tube Wall Thickness (GA) |
16GA |
| Warning |
California Proposition 65, California Proposition 65 |
| Warranty Time |
90 |
| GTIN |
00090127604106 |
